Aerogel-Based Thermal Insulation Coating for Exterior Wall Protection

Product Overview

Aerogel coating is primarily composed of SiO₂, aerogel powder, emulsion, and other additives. It features low thermal conductivity, high porosity, excellent thermal insulation, and fire resistance.

The core component, SiO₂ aerogel powder, is the key material of the coating. It is made of nano-scale silica particles through a sol-gel process combined with supercritical drying technology. The resulting structure has a porosity of over 90%, with the interior filled with air.

Key Performance Features

• Outstanding Thermal Insulation:
  Thermal conductivity ranges from 0.008 to 0.043 W/(m·K) — significantly lower than conventional insulation materials.

• Lightweight & Highly Porous:
  Density as low as 0.003–0.35 g/cm³. The material can also absorb harmful gases and purify the air.

• Fire & Corrosion Resistance:
  Excellent high-temperature tolerance and chemical stability make it ideal for construction, industrial, and other demanding applications.

Product Specifications

• Product Name: WDL-05 Exterior Wall Application

• Silica Aerogel Slurry Content: 30%

• Thermal Conductivity: 0.040 W/(m·K)

• Wet Density: 440 kg/m³

• Spray Viscosity: 145 KU

• Bond Strength: 1.0 MPa

• Packaging: 20L / Bucket

Nano Aerogel Coating – The Next-Generation Thermal Insulation Solution
Compared with traditional insulation materials, aerogel coatings feature lower thermal conductivity, higher fire resistance, easier application, and ultra-thin performance. Ideal for energy-saving, fireproof, and moisture-resistant construction projects.

Key Advantages:

• Superior Thermal Insulation:
  Thermal conductivity ≤ 0.03 W/(m·K); 3D porous structure delivers exceptional insulation performance.

• Fire & Flame Resistance:
  Rated Class A or A2 non-combustible; provides reliable protection.

• Easy Application:
  Suitable for spraying, brushing, or troweling; simple installation with minimal labor skill requirements.

• Lightweight & Space-Saving:
  Only 1–2 mm thick, reducing building load while maintaining excellent insulation.
